Professional Low Bed Trailer Truck Factory Direct Supply

Product details of the low bed trailer truck

Product Information

low bed trailer truck from Shandong Chenlu International Trade Co., Ltd. is safe and harmless. It is widely recognized with high performance and low cost. Our low bed trailer truck is certified to ISO and FDA.

Product Parameters:

State	Shandong
Material	Q235/T700
Mode of transport	By land or sea
Customs Code	87163990
Production capacity	1000 units/year
EMO/ Customisation	Customised to your needs

The low bed semitrailer series is available in flat, concave beam and exposed tire construction, straight or gooseneck. Its frame is ladder type, the longitudinal beam segment is high-density, with high stiffness and high strength characteristics.

The low main plane of the vehicle frame platform ensures the smoothness of transportation and is suitable for the transportation of various construction machinery, large equipment and steel.

Parameter:

Product Name	Low Bed semi-trailer
Size	13000x2550x2700mm (Optional)
Tire size	12 r22. 5/11 r22. 5/13 r22. 5/11.00 R20/12.00 R20 (specificationcan be Optional)
Axis	13T/16T, Fuhua/Business College/Yahua/Hongyuan brand or optional brand
Hover	Mechanical suspension (German or American) or air suspension
Payload	30T-80T
Support leg	Yost/Fuhua/Yahua brand or Chinese brand 28 tons (two speed or single speed
Main beam	Height:450 mm to 520 mm, upper plate thickness is 14 mm to 25 mm, middle plate thickness is 8 mm to 12 mm, lower plate thickness is 16 mm to 25 mm; Material is Q345 manganese steel.
Usage	Bulk cargo/container transport
Braking system	Dual line air brakes with 30 chambers for the front two axles and 30/30 chambers for the rear axles
Twist lock	Four, eight or twelve (lifting or twisting screw) optional locks for containers
Electrical system	24V, 7-pin socket, a set of 7-core standard cables

Company Advantage

• Our company manufactures our products by attaching great importance to the quality and integrity. So our products are sold well in the domestic and foreign markets.
• Since the beginning in our company has been focusing on the development of Dump semi trailer,Lowbed semi trailer,Flatbed trailer. After years of research, we have achieved remarkable results in the management and management.
• The open and smooth traffic creates convenience for the transportation and timely supply of Dump semi trailer,Lowbed semi trailer,Flatbed trailer.
Hello, if you are interested in CHENLU's tools and want to know more product details, you can leave your contact information. We will contact you as soon as possible.
