Chenlu Trailer Focus On The R D And Manufacturing Of Semi Trailers And Truck Since 2008.
Product Description:
Wide range of application: curtain semi-trailer can load bulk sundries, but also can load express goods, round-trip allocation, a wider supply of goods.
High safety of goods: its fully sealed wear-resistant side curtain fabric, high strength, corrosion and rain resistant, not only can avoid weather changes to the damage of goods, but also reduce the risk of theft, the safety of goods is guaranteed.
Loading operation is simple and convenient: the column of curtain semi-trailer can be adjusted at will, loading operation is simple and convenient, saving time and labor.
Advertising role: the curtain can be customized spray advertising, spray painting patterns, each car can be turned into a mobile billboard, can promote the company's brand well.
Light weight: Since both sides of the side curtain trailer are closed by curtain fabric, it has some outstanding advantages, one of which is that both sides of the side curtain trailer are made of soft tarp flexible materials, and after the stability pile of the fixed goods is locked and fixed, more railings can be set up above. In order to minimize the weight under the premise of ensuring the protection strength, the railings are generally made of aluminum alloy or wood. The whole car is therefore lighter than the van.
Parameter:
CURTAIN SEMI TRAILER | |
Tare weight | 8000kg |
Payload | 50000 kg |
Overall length | 13000mm |
Overall width | 2500mm |
Overall height | 4000mm |
SPECIFICATION | |
Chassis | Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, Welded by automatic submerged-Arc processes. Top flange 14mm, width140mm; Middle Flange 8mm; bottom flange16mm, height: 500mm |
Suspension | Mechanical suspension |
Leaf spring | Spring leaf 6 sets |
Floor | 3mm |
Tire | 12R22.5 12 pcs |
Wheel rim | 9.0 12 pcs |
Kingpin | 2’ bolt-in king pin |
Landing gear | JOST C200 two-speed, manual operating ,heavy duty landing gear 24t |
Cylinder | No |
Vehicular applications | Cargo transport |
Drawing | Including |
Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
Accessories | One standard tool box 1 jack 2 extinguishers 1Tire bolt sleeve |
Spare wheel carrier | 2 |
Curtain Material | Painting according to client’s requirements. |
Company Advantages
· The Chenlu Trailer semi truck dealerships provides reliable performance, and users won't have to worry about its quality.
· This product is widely appreciated by customers, with excellent performance and longer service life.
· Shandong Chenlu International Trade Co., Ltd. continues to introduce advanced management concepts from oversea markets.
Company Features
· Shandong Chenlu International Trade Co., Ltd. strengthens own advantages continually in the developing and manufacturing of semi truck dealerships. We have become an expert in this industry.
· As a company with technical competitiveness, we have a number of semi truck dealerships production lines.
· We strive to acquire the marketplace and many praised customer support with our greatest quality semi truck dealerships. Inquire!
Application of the Product
The semi truck dealerships produced by CHENLU is widely used in industry.
Before developing a solution, we will fully understand the market situation and customer's needs. In this way, we can provide effective solutions for our customers.
