Chenlu Trailer Focus On The R D And Manufacturing Of Semi Trailers And Truck Since 2008.
Quality Semi Trailer Price List
Product details of the semi trailer
Product Overview
Chenlu Trailer semi trailer is produced under highly standardized production environment. The product has consistent quality, stable performance, and long service life. There is strict institution in Shandong Chenlu International Trade Co., Ltd. for semi trailer to ensure high quality.
Product Introduction
semi trailer produced by CHENLU are of excellent quality and the specific details are as follows.
Product Description：
The characteristics of the seven-axis semi-trailer are mainly reflected in its structure. It is composed of three parts: connecting head, body and carriage, of which the most important is the carriage part. The seven-axle semi-trailer is equipped with seven axles at the bottom of the compartment, each axle is equipped with tires, so it is able to carry more weight, and has better load-bearing capacity and stability. In addition, the carriage of the seven-axle semi-trailer also has a higher space utilization rate and a more flexible loading method, which can adapt to different transportation needs.
The use of seven-axis semi-trailer is also very wide. Because of its strong bearing capacity, good stability, high space utilization, it is widely used in long-distance transportation, logistics distribution, engineering construction and other fields. For example, in long-distance transportation, seven-axis semi-trailers can be used to transport heavy goods such as large machinery and equipment and construction materials; In logistics distribution, it can be used to transport large household appliances, food and other items; In engineering construction, it can be used to transport building materials, steel and other raw materials.
Parameter:
erms | Low bed semi trailer 100T | Low bed semi trailer 120T |
Loading Capacity | 80-100 tons | 100-120 tons |
Axle | 6 pieces, 13T FUWA/BPW axle | 8pieces, 13T FUWA/BPW axle |
Tyre | 24 pieces, 10.00R20 | 32pieces, 11.00R20 |
Dimensions(LxWxH) | 13000 -17000mm x 3000 x 1750mm | |
Tare weight | 10 tons to 12 tons | |
Axle spacing | 1310mm | |
Rims | 8.5-20, 9.0-20 | |
Suspension System | Leaf spring suspension / air suspension | |
Brake System | Dual line pneumatic brake system with WABCO emergency relay valve | |
Main Beam | Height 500mm Q345 carbon steel | |
Chassis | upper 20mm, lower 20mm. Mid web 12mm | |
Rear Loading Ramps | 2 nos, 720 mm width, spring loaded & manually operated with safety chain | |
Kingpin | 2' or 3.5' interchangeable,JOST brand | |
Landing Gear | 28 Tons , Two speed manual operation | |
Electrical System | 1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard | |
Lights and Reflectors | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light | |
Painting | Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total DFT not less than 100μm;Any color will be available | |
Tool Box | One tool box with a set of standard trailer tools | |
Spare Tyre Carrier | One piece or two pieces | |
Company Advantages
For many years, Shandong Chenlu International Trade Co., Ltd. has gained rich experience and expertise in the R&D, design, manufacture, and marketing of high-quality semi trailer. Chenlu Trailer has had a group of professional technicians who have rich experience in producing semi trailer. Our mission is to be the preferred company for our consumers, customers, employees, and investors. We aim to be a highly responsible company.
We have ample inventory and discounts for large purchases. Welcome to contact us!
