Chenlu Trailer Focus On The R D And Manufacturing Of Semi Trailers And Truck Since 2008.
Professional 2 Axle Low Bed Trailer 2 Axle Low Bed Trailer Company
Product details of the 2 axle low bed trailer
Quick Overview
The production of Chenlu Trailer 2 axle low bed trailer runs smoothly and efficiently thanks to the adoption of sophisticated manufacturing equipment. It offers infinite possibilities and meets numerous needs. As long as there is any damage for 2 axle low bed trailer during transportation, we will take the responsibility.
Product Information
Compared with similar products in the market, the 2 axle low bed trailer of CHENLU has the following main advantages.
Product Description：
Lowbed semi trailers are normally used to transport heavy vehicles such as buses, rail vehicles, mining machinery, forestry machinery, agricultural machinery such as excavator, bulldozer, loader, paver, crane, and other heavy goods. The lower its center of gravity, the better its stability and safety, and the stronger its ability to transport ultra-high goods and pass overhead obstacles.Lowbed semi trailers usually adopt a four-beam frame. The front section of the frame is gooseneck (the traction pin of the front section of the gooseneck is connected with the traction saddle on the tractor, and the rear end of the gooseneck is connected with the semi trailer frame). The middle section is the trailer platform, which is the lowest part of the frame. The rear is the wheel frame including wheels. When loading mechanical equipment onto a lowbed trailer, it is usually loaded from the rear. that is, move the mechanical equipment over the rear wheel frame or remove the wheels, and then fasten the mechanical equipment on the trailer.
Parameter:
Extendable lowbed semi trailer | |
Model | LAT9402TDP |
Size | 16000*3000*1100 (mm) |
Extendable length | 3000mm-10000mm |
Payload | 60000KG-100000KG |
Main beam | Heavy duty I beam. |
Side beam | 250mm I beam |
Plate | 4mm checked plate |
Ladder | Mechanical spring ladder or hydraulic ladder |
Axles | 3 * 13ton capacity (Brand optional) |
Suspension | Mechanical suspension (Air suspension optional) |
Leaf spring | 10pcs |
Tire | 12R22.5 / 11.00R20 12pcs (Other size optional) |
Rim | 9.00-22.5 / 11.00R20 12pcs (Other size optional) |
Kin pin | 2''/3.5'' bolt type |
Landing gear | 28 Ton two speed |
Braking system | Double air chamber ,brake valve,45L air tanks ;ABS optional |
Electrical | LED light , 7 ways ,24V |
Painting | Sand blasting processing clean rust |
1 coat of anticorrosive primer | |
2 coats of finish urethane paint | |
Color as customer choice | |
Accessory | One tooling box with a set of standard trailer tool |
Usage | Is applicable for the transportations of the mechanical equipment, |
large objects, highway construction equipment, large tanks, | |
power plant equipment or machine, and all sorts of steel products. | |
Other Descriptions | The cargo platform is lower than others, |
is applicable for unsound road condition, | |
ensuring the stablenessof the transportation. | |
Other Specifications | It's concave structured with tyre appeared style, |
the height of the cargo's carrying platform from ground is 900mm, | |
(ladders belong to optional components), with the overall height of 1710 mm | |
Remark | We can design model according to client's requirement |
Company Information
As a modern enterprise, Shandong Chenlu International Trade Co., Ltd. are complete in qualifications and strong in strength. We are mainly engaged in Dump semi trailer,Lowbed semi trailer,Flatbed trailer. CHENLU adheres to the business philosophy of 'detail determines quality, integrity continues the market'. Therefore, we always strive for survival by quality, achieve development through reputation and gain benefit by management. We are committed to providing effective product solutions for customers at home and abroad. CHENLU's researchers, technicians, and quality inspectors are the powerful guarantee for continuous development. CHENLU can provide customers with one-stop solutions of high quality, and meet customers' needs to the greatest extent.
Welcome customers to cooperate with us!
